| Model | Ratio | Max Input [rpm] | Output L/R [kg.m] | Weight[kg] | Bell Housing |
|---|---|---|---|---|---|
| DPO167 | 0.6603:1 | 1,981 | 160 / 160 | 380 | 1,2 |
| 0.7255:1 | 2,177 | 160 / 160 | 380 | 1,2 | |
| 0.8333:1 | 2,500 | 160 / 160 | 382 | 1,2 | |
| 1.3784:1 | 3,500 | 160 / 160 | 392 | 1,2 |
Key features
– Independent control by 2 clutches
– Stand-by function help low consume of power
– Live pulley provided
– Versatility of Output types
– Attachable for both side of front(pulley) and rear(bell housing) of the engine
– Directly attachable with Pump pad
– SAE C D pumps are available(If required, needs processing)
– SAE C D adaptor provided
– Ships which use hydraulic accessories
– Where you need to use pumps and pulleys
– Diesel power unit system
